At Rutronik: Energy-efficient EnOcean Wireless Transceiver Module

08/30/2019 Suppliers

The compact wireless transceiver module TCM 515 is suitable for systems such as transceiver gateways, actuators and controllers that communicate based on the EnOcean radio standard in the sub-GHz band. It provides reduced power consumption, smaller size and a lower purchase price compared to the previous generation TCM 310, which is still available. Due to the higher processor performance of the TCM 515, all security features – encryption, decryption and authentication – can be performed directly in the module. This enables a secure end-to-end communication without external components. The module is available at www.rutronik24.com.

The TCM 515 module, pre-certified according to international radio standards, receives radio telegrams either via wire antenna, PCB antenna or an external 50 Ohm antenna. It can filter, decrypt and authenticate these telegrams before forwarding them to an externally connected host processor or host PC via a serial UART-interface (Universal Asynchronous Receiver Transmitter). Thanks to the integrated security processing no additional components are required for encryption.

The serial interface operates according to EnOcean ESP3 standard with the option to use higher interface speeds (TURBO mode) to reduce latencies. ESP3 messages received from the external host will be encrypted and authenticated as required before they are transmitted as EnOcean radio telegrams.

The wireless transceiver module TCM 515 / S3003-K515 supports the radio frequency
868 MHz for Europe while the TCM 515U / S3053-K515 supports 902 MHz for North America.


You will find more information on the EnOcean module on the e-commerce platform
 www.rutronik24.com (where you can also place orders directly):

www.rutronik24.com/search-result/nojs:1337/qs:S3003-K515/reset:0

Contact Person (Rutronik):
Kerstin Wagner, Product Sales Manager Wireless
Tel: +49 7231 801 1579
e-mail: kerstin.wagner@rutronik.com
