The CIPOS™ Tiny 600 V, 15 A three-phase IGBT based Intelligent Power Module comes with optimized performance and compact form factor for an inverter power rating up to 1.5HP. The new member of the IM323-family was designed especially for Room Aircon and Home appliance applications.
The energy-efficient CIPOS™ Tiny is a family of advanced IPMs (Intelligent Power Modules) developed with a focus on higher module efficiency and long-term reliability. The combined benefits of advanced trench IGBT technology and optimized package design have enabled us to achieve best-in-class efficiency and improved reliability, along with minimized system size and cost. Integrating discrete power semiconductors and drivers into one package allows designers to reduce the time and effort spent on design, significantly reducing the time-to-market.
Features
- TRENCHSTOP™ RC-D2
- C5SOI 3-phase single gate driver
- Operating range of 1 to 20 kHz
- Maximum junction temperature 175° C for the RC-D2
- Short circuit capability minimum 3μs
- Full pack DIP 32.8x18.8 mm
- Pin compatible solution
- For target applications in MHA especially for and RAC compressor up to 1.5 hp
Benefits
- Proven & enhanced package robustness for high reliability
- Full in-house production front-end and back-end for supply security
- Latest switch and gate driver technology for best perfor-mance
- Designed for fast time to market
Target applications
- Home appliances
- Industrial motor drives and controls
- Residential aircon - motor-, system control and monitoring
Competitive advantage
- Proven & enhanced package robustness for high reliability
- Full in-house production front-end and back-end for supply security
- Latest switch and gate driver technology for best performance
- Designed for ease of design in and fast time to market
