Efficient-cores (E-cores) provide high core density and exceptional performance per watt, while performance-cores (P-cores) deliver outstanding performance for a wide range of workloads, including AI and HPC.
Intel® Xeon® 6900 processors feature a new server platform design and provide customers with high performance and memory bandwidth, as well as high throughput, making them ideal for cloud, HPC and AI environments. They feature a higher number of cores, more memory channels and I/O lanes with thermal design points higher than the other series.
The Intel® Xeon® 6700/6500 processors come in an updated server platform design with high performance and cost- and energy-efficient solutions that are ideal for a variety of data center environments. The processors are available in one-socket to eight-socket options and feature improved I/O and memory capacities that fit into the established power and cooling dimensions of data centers.
Intel® Xeon® 6 SoCs with P-cores enable better performance per watt in a single-socket platform design. Designed for edge and network applications, this SoC offers PCIe 5.0 lanes, integrated Ethernet, higher memory bandwidth compared to the previous generation, and significant improvements to the integrated Intel® Accelerator Engines.
Intel® Xeon® 6300 processors series processors provide robust performance, expandability, and reliability for entry-level server solutions. These power- and cost-efficient processors support two channels of DDR5 memory, delivering speeds up to 4,800 MT / s and 16-lane PCIe 5.0 for fast networking and storage.
Key features of Intel® Xeon® 6 processors with P-Cores:
- Up to 128 cores (256 threads) per CPU
- Up to 500 W TDP per CPU
- Server designs with one, two, four or eight sockets
- Up to 12 memory channels
- Up to 6,400 MT / s DDR5
- MRDIMMs deliver up to 8,800 MT / s
- Up to 192 PCIe 5.0 lanes for two-socket server designs
- Options with up to 136 lanes for single-socket server designs
- Intel Ultra Path Interconnect (UPI) 2.0
- Intel AMX
- Intel AVX-512
Recommended use cases for Intel Xeon 6 Processors with P-cores:
- High-performance computing
- Modeling and simulation
- CAE
- Database and analytics
- CRM, ERP
- Big data
- In-memory analytics
- AI
- Generative AI
- Deep learning/machine learning
- Inference
- Infrastructure and storage
- HCI
- Virtualization
- Storage
Networking
- Media and Gaming
- Cloud-Native CDN
Edge
- Video
- Edge Analytics
- Key features of Intel® Xeon® 6 processors with E-cores:
- Up to 288 cores (288 threads) per CPU
- Up to 500 W TDP per CPU
- Single- and two-socket server designs
- Up to 12 memory channels
- Up to 6,400 MT / s DDR5
- Up to 192 PCIe 5.0 lanes for two-socket server designs
- Intel Ultra Path Interconnect (UPI) 2.0
- Intel AVX2
- Recommended use cases for Intel® Xeon® 6 Processors with E-cores:
- Web & Microservices
- Cloud-Native
- Consumer Digital Services
- Application Dev Ops
- Database & Analytics
- Unstructured Databases
- Scale-Out Analytics
- Infrastructure & Storage
- Storage
- Networks
- CDN
- Network Microservices
- 5G Core
- Edge
- Virtual Protection Relay
Further information can be found in the corresponding Rutronik TEC article.
For more information to the Xeon® 6 processor family by Intel® and a direct ordering option, please visit our e-commerce platform at www.rutronik24.com. |
