AL5873Q

The AL5873Q is an automotive-compliant three-channel linear LED driver with PWM dimming and analog dimming control. Each channel can drive up to 250mA with a combined driving current up to 750mA. All three LED channels’ current of the AL5873Q are set by two reference resistors connected to the REF1 and REF2 pin. The AL5873Q regulates LED current for each channel, accurate down to ±4%, with excellent dimming performance. The AL5873Q enters standby mode to save power if no PWM signal is detected.

The AL5873Q monitors the temperature and reduces the LED current if its juncture temperature exceeds the threshold temperature. For improved system robustness the AL5783Q has input under voltage lock-out (UVLO), LED string-open /-short protection, and overtemperature protection (OTP) which are reported by a fault indicator (FAULTB) pin. The AL5873Q is available in TSSOP-16EP (Type DX) package.

Application(s)

Automotive LED Inner Lamps
Rear Light – Tail and Stop Light, Rear Turn Indicator, Parking Light, Fog Light, Reverse Light

Feature(s)

AEC-Q100 Grade 1 Qualification
Wide Input Voltage Range from 5V to 55V
Each Channel Up to 250mA Current Capability
Set Stop and Tail Current Independently Through 2 Resistors
Switch LED Current Between Stop and Tail Function Automatically via FULL Input
PWM Dimming via Both PWM Input and Power Supply
Analog Dimming via ADIM Input
Automatically Enter and Exit Standby Mode without Enable Pin
Internal Protections:
- Input Under Voltage Lock-Out (UVLO)
- LED String Open Protection
- LED String Short Protection
- Over Temperature Protection (OTP)
Thermal Fold-back if Chip Temperature Exceeds the Threshold
Fault Reporting: UVLO, OTP, LED Open, and LED Short
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
The AL5873Q is suitable for automotive applications requiring specific change control; this part is AEC-Q100 qualified, PPAP capable, and manufactured in IATF 16949 certified facilities.

New Diodes AL5873Q with Automotive Three-Channel Linear LED Driver

See in Shop

Download Datasheet

Contact

PI4IOE5V6416Q / PI4IOE5V6534Q

The PI4IOESV6416Q is a 16-bit general-purpose I/O expander that provides remote I/O expansion for most microcontroller families via the l2C-bus interface.

It provides a simple solution when additional I/Os are needed while keeping interconnections to a minimum, for example, in battery-powered mobile applications for interfacing to sensors, push buttons, keypad, etc.

It can operate from 1.65 V to 5.5 V on the GPIO-port side and 1.65V to 5.5 V on the SDA/SCL side. This allows the PI4IOE5V6416Q to interface with next generation microprocessors and microcontrollers on the SDA/SCL side, where supply levels are dropping down to conserve power.

The bidirectional voltage-level translation in the PI4IOE5V6416Q is provided through VDD (I2C_bus). VDD (I2C_bus) should be connected to the VDD of the external SCL/SDA lines. The voltage level on the GPIO-port of the PI4IOE5V6416Q is determined by VDD(P).

At power on, the I/Os are configured as inputs; however, the system master can enable the I/Os as either inputs or outputs by writing to the I/O direction bits. The data for each input or output is kept in the corresponding Input or Output register. All registers can be read by the system master.

PI4IOESV6416Q has open-drain interrupt (INT) output pin that goes LOW when the input state of a GPIO-port changes from the input-state default register value. The device also has an interrupt masking feature by which the user can mask the interrupt from an individual GPIO port.

Feature(s)

Operation power supply voltage from 1.65 V to 5.5 V
Allows bidirectional voltage-level translation and GPIO expansion between:
1.8/2.5/3.3/5 V SCL/SDA and 1.8/2.5/3.3/5 V Port
Low standby current consumption:
1.5 µA typical at 5 V VDD
1 µA typical at 3.3 V VDD
400 kHz I2C-bus interface
Compliant with the I2C-bus Fast and Standard modes
Programmable Push-pull/Open-drain output stages
Programmable output drive strength and pull-up/down resistor
Power-on reset
Active LOW open-drain interrupt output
Active LOW reset input
Latch-up tested (exceeds 100 mA)
Support AEC-Q100 (Grade 2)
Totally Lead-Free & Full RoHS Compliant
Halogen and Antimony Free. "Green" Device The PI4IOE5V6416Q is suitable for automotive applications requiring specific change control; the part is AEC-Q100 qualified, PPAP capable, and manufactured in IATF 16949 certified facilities.
Packaging (Pb-free & Green)

The PI4IOE5V6534Q is a 34bit general-purpose I/O expander that provides remote I/O expansion for most microcontroller families via the FC-bus interface.

The device provides a simple solution when additional I/Os are needed while keeping interconnections to a minimum. for example, in battery-powered mobile applications for interfacing to sensors, push buttons, keypad, etc.

The expander IC can operate from 1.65 V to 5.5 V on the GPIO-port side and 0.8V to 3.6 V on the SDA/SCL side. This allows the PI4IOE5V6534Q to interface with next generation microprocessors and microcontrollers on the SDA/SCL side, where supply levels are dropping down to conserve power.

The VDD(I2C-bus) in PI4IOESV6534Q provides bidirectional voltage-level translation, and the pin should be connected to the VDD of the external SCL/SDA lines. The voltage level on the GPIO port of the PI4IOE5V6534Q is determined by VDD(P)

At power-on, the I/Os are configured as inputs, however, the system master can enable the I/Os as either inputs or outputs by writing to the I/O direction bits. The data for each input or output is kept in the corresponding Input or Output register. All registers can be read by the system master.

PI4IOE5V6534Q has open-drain interrupt (INT) output pin that goes LOW when the input state of a GPIO-port changes from the input-state default register value. The device also has an interrupt masking feature, which the user can use to mask the interrupt from an individual GPIO-port.

Feature(s)

Operating power supply voltage range of 8 V to 3.6 V on the I²C-bus side
Allows bidirectional voltage-level translation and GPIO expansion between:
8 V to 3.6 V SCL/SDA and 1.8/2.5/3.3/5.5 V Port
Low standby current consumption:
2μA typical at 3.3 V VDD(P)
5V tolerant I/O ports and 3.6 V tolerant I2C-bus pins
1MHz Fast-mode Plus I2C-bus interface
Compliant with the I²C-bus Fast-mode plus, Fast-mode and Standard mode
I/O Features
Output port configurations: bank selectable or pin selectable push-pull or open-drain output stages
Interrupt status: read-only register identifies the source of an interrupt
I/O programming features:
Output drive strength: four programmable drive strengths to reduce rise and fall times in low-capacitance applications
Input latch: Input Port register values changes are kept until the Input Port register is read
Pull-up/pull-down enable: floating input or pull-up/pull-down resistor enable
Pull-up/pull-down selection: 100 k-ohm pull-up/pull-down resistor selection
Interrupt mask: mask prevents the generation of the interrupt when input changes state to prevent spurious interrupts
Interrupt edge specification on a bit-by-bit basis
Interrupt individual clear without disturbing other events
Read all interrupt events without clear
Switch debounce hardware
General call software reset
I²C software Device ID function
Power-on reset
Active LOW open-drain interrupt output (INT)
Active LOW reset input (RESET)
Latch-up tested (exceeds 100mA)
Latched Outputs for Directly Driving LEDs
AEC-Q100 (Grade 2)
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
The PI4IOE5V6534Q is suitable for automotive applications requiring specific change control; this part is AEC-Q100 qualified, PPAP capable, and manufactured in IATF 16949 certified facilities.
Packaging (Pb-free & Green):
46-Pin, Wettable TQFN 4.5x6.5mm (ZLW)

New Diodes PI4IOE5V6416Q and PI4IOE5V6534Q automotive dual-power rail I2C bus gpdio expanders

See PI4IOE5V6416Q in Shop

See PI4IOE5V6534Q in Shop

Download Datasheet

Contact

PI2DPX1217, PI2DPX1066, PI2DPX1263

The PI2DPX1217 is a non-blocking USB Type-C® DP-Alt mode linear ReDriver™ in 4-to-4 configuration operated by 1.8v power supply. It supports four operation modes through I2C bus setting for USB3.2 Gen2, USB3.2 Gen2/2-lane DP1.4/DP2.0 (UHBR10), 4-lane DP1.4/ DP2.0 (UHBR10) or USB3.2 Gen2x2 with speed up to 10 Gbps per channel. It swaps the high speed channels under the flip and non-flip plug in compliance to Type-C connector with the integrated AUX crossbar switch for SBU pins. The non-blocking linear Redriver design ensures the differential signals conveying pre-shoot and de-emphasis equalization waveforms from transmitter side to receiver side, this can help to optimize the overall channel link adjustment conducted by the system transmitter and receiver with DFE. The CTLE equalizers are implemented at the inputs of the Redriver to compensate the channel loss and reduce the ISI jitters. The programmable flat gain and linearity adjustments support the eye diagram opening. The CTLE EQ gains, flat gains and linearity are individually programmable on each channel for flexible tuning via I2C register settings. USB channel by-pass mode is initialized at power-on as default mode to support factory setting especially for the system with only Type-C connector.

Application(s)

Smart Phones
Tablets
Laptop PCs
Gaming Consoles
VR/AR Goggles
Active Cables

Feature(s)

4-to-4 channel configuration with 10Gbps linear Redriver
Configurable for USB3.2 Gen2, USB3.2 Gen2/2-lane DP1.4/ DP2.0 (UHBR10), 4-lane DP1.4/DP2.0 (UHBR10) or USB3.2 Gen2x2 operations
Default USB3.2 Gen2x2 bypass operation during power on
Ultra low latency (< 300ps) for better interoperability and data throughput
Individual controls on CTLE gain, Flat Gain and Output linearity
Integrated AUX channel crossbar switch for side band signal
Type-C connector flip and non-flip plug support
I2C Slave support with speed up to 1MHz
Very low USB and DisplayPort active mode and power saving mode operation
Single power supply: 1.8V +/-5%
Industrial temperature support: -40C to +85C
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative.
Packaging (Pb-free & Green): Tiny 32-pin X2QFN, (0.4 mm pitch) (XUA)

USB-C® is a registered trademark of the USB Implementers Forum. ReDriver™ is a trademark of Diodes Incorporated.

The PI2DPX1066 is a non-blocking USB Type-C® DP-Alt mode linear ReDriver™ in 4-to-4 configuration operated by 1.8v power supply. It supports four operation modes through I2C bus setting for USB3.2 Gen2, USB3.2 Gen2/2-lane DP1.4/DP2.0 (UHBR10), 4-lane DP1.4/DP2.0 (UHBR10) or USB3.2 Gen2x2 with speed up to 10Gbps per channel. It swaps the high speed channels under the flip and non-flip plug in compliance to Type-C connector with the integrated AUX crossbar switch for SBU pins. The non-blocking linear Redriver design ensures the differential signals conveying pre-shoot and de-emphasis equalization waveforms from transmitter side to receiver side, this can help to optimize the overall channel link adjustment conducted by the system transmitter and receiver with DFE. The CTLE equalizers are implemented at the inputs of the Redriver to compensate the channel loss and reduce the ISI jitters. The programmable flat gain and linearity adjustments support the eye diagram opening. The CTLE EQ gains, flat gains and linearity are individually programmable on each channel for flexible tuning via I2C register settings.

Application(s)

Laptop PCs
Desktop PCs
Gaming Consoles
VR/AR Goggles
Active Cables

Feature(s)

4-to-4 channel configuration with 10Gbps linear Redriver
Configurable for USB3.2 Gen2, USB3.2 Gen2/2-lane DP1.4/ DP2.0 (UHBR10), 4-lane DP1.4/DP2.0 (UHBR10) or USB3.2 Gen2x2 operations
Default USB Type-C safe state (Hi-Z) after power-on
Ultra low latency (< 300ps) for better interoperability and data throughput
Individual controls on CTLE gain, Flat Gain and Output linearity
Integrated AUX channel crossbar switch for side band signal
Type-C connector flip and non-flip plug support
I2C Slave support with speed up to 1MHz
Very low USB and DisplayPort active mode and power saving mode operation
Single power supply: 1.8V +/-5%
Industrial temperature support: -40C to +85C
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative.
Packaging (Pb-free & Green):
Tiny 32-pin X2QFN, (0.4 mm pitch) (XUA)

USB-C® is a registered trademark of the USB Implementers Forum. ReDriver™ is a trademark of Diodes Incorporated.

The PI2DPX1263 is a non-blocking DisplayPort2.0/DP1.4 linear DisplayPort™ with four channels operated by 1.8V power supply. The device supports UHBR10 (10Gbps), HBR3 (8.1Gbps), HBR2 (5.4Gbps), and RBR under various DisplayPort speeds. With the on-chip AUX channel listener, the device can automatically monitor the system operation status to enter power saving mode via the DPCD register traffic check and activate the negotiated lane count for operation. The non-blocking linear ReDriver™ design ensures the differential signals conveying pre-shoot and de-emphasis equalization waveform messages from transmitter side to receiver side, which helps optimize the overall channel link adjustment conducted by the system transmitter and receiver with DFE. The CTLE equalizers are implemented at the inputs of the ReDriver to compensate the channel loss and reduce the ISI jitters. The programmable flat gain and linearity adjustments support the eye diagram opening. The CTLE EQ gains, flat gains, and linearity are individually programmable on each channel for flexible tuning via I2C register settings.

Application(s)

Laptop PCs
Desktop PCs
Gaming Consoles
VR/AR Goggles
Active Cables
Embedded Display Panels

Feature(s)

4-Channel Configuration with 10Gbps Linear ReDriver
Supports the Channel Speed up to 10Gbps DP2.0 (UHBR10)
Ultra-Low Latency (< 300ps) for Better Interoperability and Data Throughput
Individual Controls on CTLE Gain, Flat Gain, and Output Linearity
Integrated AUX Channel Listener for D3 Power Saving Mode
I2C Slave Support with Speed up to 1MHz
Very-Low DisplayPort Active Mode and Power Saving Mode Operation
Interchangeable Input Channel Polarity
Single Power Supply: 1.8V ±5%
Industrial Temperature Support: -40°C to +85°C
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative.
